Railroad Elastic Rail Clips E Type W Type 47HRC 42HRC Hardness 55Si2Mn Material

Railroad Elastic Rail Clips E Type W Type 47HRC 42HRC Hardness 55Si2Mn Material
Railroad Elastic Rail Clips E Type W Type 47HRC 42HRC Hardness 55Si2Mn Material
Railroad Elastic Rail Clips E Type W Type 47HRC 42HRC Hardness 55Si2Mn Material Railroad Elastic Rail Clips E Type W Type 47HRC 42HRC Hardness 55Si2Mn Material Railroad Elastic Rail Clips E Type W Type 47HRC 42HRC Hardness 55Si2Mn Material Railroad Elastic Rail Clips E Type W Type 47HRC 42HRC Hardness 55Si2Mn Material Railroad Elastic Rail Clips E Type W Type 47HRC 42HRC Hardness 55Si2Mn Material Railroad Elastic Rail Clips E Type W Type 47HRC 42HRC Hardness 55Si2Mn Material

Large Image :  Railroad Elastic Rail Clips E Type W Type 47HRC 42HRC Hardness 55Si2Mn Material

Product Details:
Place of Origin: China
Brand Name: Kingrail
Certification: GB/T 1222,DIN 17221,CE
Model Number: SKL12
Payment & Shipping Terms:
Minimum Order Quantity: 10000
Price: USD$1-10 PER PC
Packaging Details: bulk bags and pallets or customized package
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100000000PCS PER YEAR

Railroad Elastic Rail Clips E Type W Type 47HRC 42HRC Hardness 55Si2Mn Material

Description
Material: 55Si2Mn Color: Black Or Plain
Hardness: 42-47HRC Fatigue Life: 5 Millions Cycles Without Breaking
Surface: Plain (oiled), Oxide Black, Color Painting Standard Refers: GB/T 1222,DIN 17221
Diameter: ø13 Name: Railroad Fasteners Skl12 Elastic Rail Clip Manufacturer Elastic Rail Clip E Type & W Type
High Light:

42HRC Elastic Rail Clip

,

47HRC Elastic Rail Clip

,

55Si2Mn Railroad Rail Clips

Railroad Fasteners Skl12 Elastic Rail Clip Manufacturer Elastic Rail Clip E Type & W Type





Product Description

Railway parts is the root causes of vibration,supplier of china ,railway clip in order to overcome the vibration source, reduce the occurrence of rail joint diseases, use of railway fasteners is the best choice. increases the joint resistance.ensure that the railway transport safety. Therefore, the construction of the railway cargo rail transit from railway fasteners "support". The structure is compact, buckle pressure big, keep track ability, less workload maintenance , especially suitable for the large mechanical work line.our mainly export railway spring clips type have e1809 e1609 e1813 e1817 e2001 e2007 e2009 e2055 e2056 e2063 PR401 PR415 PR601 SKL-1 SKL-3 etc.

Railroad Elastic Rail Clips E Type W Type 47HRC 42HRC Hardness 55Si2Mn Material 0
Product detials :Railroad Fasteners Skl12 Elastic Rail Clip Manufacturer Elastic Rail Clip E Type & W Type

Name

Railroad Fasteners Skl12 Elastic Rail Clip Manufacturer Elastic Rail Clip E Type & W Type

Material

60Si2MnA

60Si2CrA

55Si2Mn

38Si7

Chemical composition(%)

C:0.56-0.64, Mn:0.60-0.90, Si:1.60-2.00, Cr:≤0.35, P:≤0.03, S:≤0.03

C:0.56-0.64, Mn:0.40-0.70, Si:1.40-1.80,Cr:0.70-1.00 P:≤0.03, S:≤0.03

C:0.52-0.60, Mn:0.60-0.90, Si:1.50-2.00,Cr:≤0.35 P:≤0.03, S:≤0.03

C:0.35-0.42, Mn:0.50-0.80, Si:1.50-1.80, P:≤0.03, S:≤0.03


Hardness

HRC 42-47


Fatigue life


5 millions cycles without breaking


Surface

Plain (oiled), Oxide black, color painting

Standard refers


GB/T 1222,DIN 17221



Railroad Elastic Rail Clips E Type W Type 47HRC 42HRC Hardness 55Si2Mn Material 1



Railroad Fasteners Railroad Fasteners Skl12 Elastic Rail Clip Manufacturer Elastic Rail Clip E Type & W Type Parameter

Description Specification Material
Fish Bolt 22×135, 24×135, 24×145 Q235
High-strength Fish Bolt 22×135, 24×135, 24×145 C45
Insulated Bolt 22×160, 24×160, 24×170 C45
T type bolt M24x110 Q235
Flat Washer 6×25×50 Q235
Spring Washer 20×8, 24×8, 26×8
Double Spring Washer 26×8
Screw Spike M22x185, M24x195 Q235
Square head screw spike 22x145, 22x155, 22x165 Q235A
Hexagon screw spike 22x145, 22x155, 22x165, 22x185, 22x195 Q235A
Dog Spike 16×165
Gauge apron 10#, 13#, 14#, 20# Q235
Antiseptic gauge apron 10# Q235
Steel Tie plate/ base plate   QT450-10
Rail anchor   QT450-10, Q235A, QT400-15
Rubber tie plate P43, P50, P60 Rubber
Elastic rail clip A,B Type 60Si2Mn
SKL serious Type 60Si2Cr, 38Si7
G Type 60Si2MnA
W Type
Antiseptic elastic rail clip B Type 60Si2MnA
Nylon apron block V type, 0-4#, 2-6# polyamide 66
Insulated Rail Gauge Rod ¢32, ¢36
Rail Gauge Rod ¢32, ¢36
Fish plate 43kg, 50kg, 60kg, 75kg B7. 45#
BS60, BS75R, BS80A, BS90A B6, B7
Insulated fish plate (43, 50, 60, 75).. B6, B7
UIC60, UIC54 50#, 45#



Railroad Fasteners Railroad Fasteners Skl12 Elastic Rail Clip Manufacturer Elastic Rail Clip E Type & W Type
Rail clips processing procedures
1. Raw material: Premium grade spring steel sourced from a reliable and certified long term producer.
2. Shearing: The spring steel bar has to be sheared as per length required.
3. Heating: to forging temperature (950-1000 degrees Celsius), but over heating shall be avoided to check decarburization.
4. Forming: Proper heated bar is transferred to power press for forging.
5. Hardening: The forged rail clips are transferred to quenching tank. Dimensional accuracy and quench hardness of rail clips are checked before tempering.
6. Tempering: The rail clips are tempered at about 350 Celsius to achieve appropriate toughness in the spring.
7. Inspection: The products are then checked thoroughly as per China CRCC and customer required specification and design.
8. Packing: Clips can be packed in woven bags or upon customer requirement.

Railroad Elastic Rail Clips E Type W Type 47HRC 42HRC Hardness 55Si2Mn Material 2
Company Introduction:


Kingrail , your trustworthy rail clips manufacturer
Enriched with rich railway industrial experience, Kingrail can offer its clients an extensive range of heavy duty rail fastening clips, made up of premium quality and seamless performance, to be used to fasten rails to underlying tie plates. The rail clips produced by Kingrail are made up of premium grade spring steel sourced from a reliable and certified long term producer. After over 20 years' experience on producing rail elastic clips, AGICO has become the largest and most competitive production base of rail clips in China, qualified to tender nationally large and medium scaled rail projects under the China Ministry of Railways, both at home and abroad.


At each single step of manufacturing the clips are stringently tested and completely authenticated. To save time during installation in track, we can provide a special service by pre assembling a SKL clip with a T-bolt and a washer for the customer at our production base before delivery. Besides, corrosion protection layer of the clip surface can be applied.



Railroad Fasteners Skl12 Elastic Rail Clip Manufacturer Elastic Rail Clip E Type & W Type

Standard UIC standard BS standard JIS standard ISCR standard China standard South-American standard
Type UIC 54 / UIC 60 BS60A / BS75A / BS80A JIS37 / JIS50 ISCR50 / ISCR60 / ISCR70 A(I II) / B / III TJ45 / TJ57
Material 45#,55#,etc



Kingrail Rail Clips
For meeting various needs of clients, Kingrail Rail supplies E-clips, PR clip, SKL clips, Russia rail clip, Deenik clip, Nabla spring blade, KPO rail calmp, gantrex rail clips, fast clip, crane rail clip and other special clips for rails. We have proffesional production cline to design and manufacture standard rail clips or nonstandard clips. welcome to as.

Hot Rail clips from Kingrail
Series Model Spec. Hardness
E rail clip III type rail clip ø18 44-48HRC
E1609 rail clip ø16
E1809 rail clip ø20
E1804 rail clip ø18
E1806 rail clip ø18
E1813 rail clip ø18
E2001 rail clip ø20
E2007 rail clip ø20
E2009 rail clip ø20
E2039 rail clip ø20
E2055 rail clip ø20
E2056 rail clip ø20
E2063 Rail Clip ø20
E2091 Rail Clip ø20
PR rail clip PR85 Rail Clip ø13 44-48HRC
PR309A Rail Clip ø19
PR401 Rail Clip ø20
PR415 Rail Clip ø20
PR601A Rail Clip ø22
Vossloh clip& Forged rail clip SKL 1 Rail Clip ø13 42-47HRC
SKL 3 Rail Clip ø13
SKL 12 Rail Clip ø13
SKL 14 Rail Clip ø14
Special rail clip Special rail clip ø13
Russia rail clip Russia rail clip ø18
Deenik clip Deenik clip ø25
Anti-vandal clip Anti-vandal clip ø18
Fast clip Fast clip ø15
GL1419 GL1419 ø14
Nabla Spring blade Nabla Spring blade
KPO/rail clamp KPO/rail clamp
RAIL CLIP GANTREX RAIL CLIP GANTREX
We can also produce customized rail clips according to your drawings or samples!



Railway parts products we can provide:

1, Rail Spike Series: Rail Screw Spike, rail Dog Spike, rail Elastic Spike etc.

2, Track Bolt series: Track Bolt, Segment Bolt, Metro Bolt, Tunnel Bolt, Hex Bolt, Square Bolt, Turnout Bolt, Fishtail Bolt, T bolt etc

3, Rail Clip series: Nabla rail Clip, Elastic rail Clip, SKL rail Tension Clamp, O rail Clip, Gauge Lock Clip etc

4, Steel Rails series: Railway rails, Crane Rails, Mining Rails, Over the head Rails, etc

5, Steel rail wheels series: Train Wheels, Crane Wheels, Hi-rail vehicle wheels, etc

6, Other materials and accessories: Rail Gauge Insulator, rail rubber Pad, rail Fish plate, Nut, rail Plastic Dowel, rail Tie plate, Spring Washer, Flat Washer, Cast Iron Insert, Anti Creeper, rail Gauge Rod etc.

Railroad Elastic Rail Clips E Type W Type 47HRC 42HRC Hardness 55Si2Mn Material 3
Why choose us:

1. The company is in a leading position in the industry and has obtained SGS-ISO9001: 2008 quality system certification and CRCC certification. Quality is guaranteed.

2. We have 8 professional sales staff and more than 60 professional engineers. Can provide professional and fast suggestions and quotations for your railway customized products

3. Ma′anshan is a port city. We can provide you with faster shipping services

4. 20 years of production and sales experience. Deal with all kinds of after-sales problems for you in time.
