| Brand Name: | KINGRAIL |
| Model Number: | KP |
| MOQ: | 1pc |
| Price: | negotiable |
| Packaging Details: | export packzge |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Features of hand-push handrails KP unpowered rail with 4 wheels axle load till 200ton
KP series unpowered rail car, also known as "rail trailer", "rail trolley", "rail trolley by hand", is generally used in the occasion of small load and short-distance transportation of materials. Railcars that are pushed or pulled by artificial or other external forces.
KP series unpowered rail cars can be installed with traction lugs, hand-push handrails and other devices according to the requirements of users.
According to the user's requirements, other process devices can be installed on the table top of the KP series unpowered rail car, or the table top of the car can be deformed and improved according to the user's needs.
A rail trailer self-leveling device with buffering and braking functions, including a frame, a slidable carriage, a carriage pulley track, a leveling buffer mechanism and a braking system, the leveling buffer mechanism is provided between the slidable carriage and the frame The leveling buffer mechanism includes a tension spring assembly, a tension spring slider slider, a compression spring assembly and a compression spring slider slider, the braking system is arranged between the slidable carriage and the frame, and includes a first detection system, a second detection system, an industrial steering gear, and a brake hook, the first detection system is used to detect the pitch angle of the slidable carriage, the second detection system is used to detect the acceleration of the vehicle frame, and then to the industrial steering gear Send a pulse signal to make the brake hook coaxially connected with the industrial steering gear rotate synchronously, and finally make the brake hook rotate with the industrial steering gear to the serrated slot on the curved front pulley track. The invention has the advantages of simple and reliable structure, simple operation, and effective self-leveling without additional power.
The color of the car body can also be sprayed according to the user's requirements.
| hand-push handrails KP unpowered rail with 4 wheels axle load till 200ton | ||||||||||||||
| Flat car model | KPX-2t | KPX-5t | KPX-10t | KPX-16t | KPX-20t | KPX-25t | KPX-30t | KPX-40t | KPX-50t | KPX-63t | KPX-80t | KPX-100t | KPX-150t | |
| Rated load capacity (t) | 2 | 5 | 10 | 16 | 20 | 25 | 30 | 40 | 50 | 63 | 80 | 100 | 150 | |
| Table size (mm) |
long(L) | 2000 | 3500 | 3600 | 4000 | 4000 | 4500 | 4500 | 5000 | 5500 | 5600 | 6000 | 6500 | 10000 |
| width(W) | 1500 | 2000 | 2000 | 2000 | 2200 | 2200 | 2200 | 2400 | 2400 | 2400 | 2600 | 2800 | 3000 | |
| high(H) | 150 | 500 | 500 | 550 | 550 | 600 | 600 | 650 | 650 | 700 | 800 | 900 | 1200 | |
| wheelbase(mm) | 1200 | 2500 | 2600 | 2800 | 2800 | 3200 | 3200 | 3800 | 4200 | 4300 | 4700 | 4900 | 7000 | |
| Inside distance of rail(mm) | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1800 | 2000 | 2000 | |
| Wheel diameter(mm) | Φ270 | Φ300 | Φ300 | Φ350 | Φ350 | Φ400 | Φ400 | Φ500 | Φ500 | Φ600 | Φ600 | Φ600 | Φ600 | |
| Number of wheels (pcs) | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 | |
| Ground clearance(mm) | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 | 75 | 75 | |
| running speed(m/min) | 0-25 | 0-25 | 0-25 | 0-20 | 0-20 | 0-20 | 0=20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-18 | |
| Motor Power(kw) | 1 | 1.2 | 1.6 | 2 | 2.2 | 3 | 3.5 | 4 | 5 | 6.3 | 8 | 10 | 15 | |
| Battery capacity(Ah) | 180 | 180 | 160 | 180 | 180 | 250 | 250 | 300 | 330 | 400 | 400 | 440 | 600 | |
| battery voltage(V) | 24 | 36 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 72 | 72 | 72 | |
| Full load continuous running time | 4.32 | 5.4 | 4.8 | 4.3 | 4 | 4 | 3.5 | 3.6 | 3.3 | 3 | 3.6 | 3.2 | 2.9 | |
| recharge mileage(km) | 6.5 | 8.1 | 7.2 | 5.1 | 4.8 | 4.8 | 4.2 | 4.3 | 4 | 3.6 | 4.3 | 3.8 | 3.2 | |
| ***Large wheel pressure(KN) | 14.4 | 25.8 | 42.6 | 64.5 | 77.7 | 94.5 | 110.4 | 142.8 | 174 | 221.4 | 278.4 | 343.8 | 265.2 | |
| reference weight(t) | 2.8 | 3.6 | 4.2 | 5.5 | 5.9 | 6.5 | 6.8 | 7.6 | 8 | 10.8 | 12.8 | 14.6 | 26.8 | |
| Recommended rail model | P15 | P18 | P18 | P24 | P24 | P38 | P38 | P43 | P43 | P50 | P50 | QU100 | QU100 | |
| Description: 1. Load capacity, table size, rail inner distance can be designed and manufactured according to customer needs; 2. Optional wireless remote control device (domestic or imported); 3. Optional automatic stop when encountering people, limit limit device; 4. Optional maintenance-free battery, lithium battery, explosion-proof battery, high temperature battery, etc.; 5. Optional DC brush motor, DC brushless motor; 6. Optional domestic electrical appliances, imported electrical appliances. |
||||||||||||||
Manufacturer strength of hand-push handrails KP unpowered rail with 4 wheels axle load till 200ton
|
