| Brand Name: | KINGRAIL |
| Model Number: | KP-5T |
| MOQ: | 1pc |
| Price: | negotiable |
| Packaging Details: | export packzge |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Unpowered Road Rail Vehicle 4 Wheels By Hand 600mm Wheel Diameter
Features of KP-5T unpowered rail car for rail trolley by hand with 4 wheels running on various track gauges
KP series unpowered rail car, also known as "rail trailer", "rail trolley", "rail trolley", is generally used in the occasion of small load and short-distance transportation of materials. Railcars that are pushed or pulled by artificial or other external forces.
KP series unpowered rail cars can be installed with traction lugs, hand-push handrails and other devices according to the requirements of users.
According to the user's requirements, other process devices can be installed on the table top of the KP series unpowered rail car, or the table top of the car can be deformed and improved according to the user's needs.
The color of the car body can also be sprayed according to the user's requirements.
A self-leveling device for a track trailer includes a frame, a slidable car board, a wheel pulley track, a ratchet reducer, and a shock absorbing mechanism; two sets of the wheel pulley track are arranged parallel to each other on both sides of the frame The slidable car board is slidably installed on the two sets of car board pulley tracks through its two front pulleys and two rear pulleys, and can slide on the two sets of car board pulley tracks, and is slidable through the car board pulley tracks. The car board is adaptively adjusted and limited, the shock absorption mechanism is arranged between the frame and the slidable car board, and the ratchet reducer is arranged at the rear end of the slidable car board. The slidable deck is stabilized, enabling self-leveling of the slidable deck. The invention solves the problem that the rail trailer can complete self-leveling without additional power, reduces the extrusion and wear of the crops on the trailer due to the tilt of the trailer, improves the transportation efficiency and improves the economic benefit of the grower
| KP-5T unpowered rail car for rail trolley by hand with 4 wheels running on various track gauges | ||||||||||||||
| Flat car model | KPX-2t | KPX-5t | KPX-10t | KPX-16t | KPX-20t | KPX-25t | KPX-30t | KPX-40t | KPX-50t | KPX-63t | KPX-80t | KPX-100t | KPX-150t | |
| Rated load capacity (t) | 2 | 5 | 10 | 16 | 20 | 25 | 30 | 40 | 50 | 63 | 80 | 100 | 150 | |
| Table size (mm) |
long(L) | 2000 | 3500 | 3600 | 4000 | 4000 | 4500 | 4500 | 5000 | 5500 | 5600 | 6000 | 6500 | 10000 |
| width(W) | 1500 | 2000 | 2000 | 2000 | 2200 | 2200 | 2200 | 2400 | 2400 | 2400 | 2600 | 2800 | 3000 | |
| high(H) | 150 | 500 | 500 | 550 | 550 | 600 | 600 | 650 | 650 | 700 | 800 | 900 | 1200 | |
| wheelbase(mm) | 1200 | 2500 | 2600 | 2800 | 2800 | 3200 | 3200 | 3800 | 4200 | 4300 | 4700 | 4900 | 7000 | |
| Inside distance of rail(mm) | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1800 | 2000 | 2000 | |
| Wheel diameter(mm) | Φ270 | Φ300 | Φ300 | Φ350 | Φ350 | Φ400 | Φ400 | Φ500 | Φ500 | Φ600 | Φ600 | Φ600 | Φ600 | |
| Number of wheels (pcs) | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 | |
| Ground clearance(mm) | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 | 75 | 75 | |
| running speed(m/min) | 0-25 | 0-25 | 0-25 | 0-20 | 0-20 | 0-20 | 0=20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-18 | |
| Motor Power(kw) | 1 | 1.2 | 1.6 | 2 | 2.2 | 3 | 3.5 | 4 | 5 | 6.3 | 8 | 10 | 15 | |
| Battery capacity(Ah) | 180 | 180 | 160 | 180 | 180 | 250 | 250 | 300 | 330 | 400 | 400 | 440 | 600 | |
| battery voltage(V) | 24 | 36 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 72 | 72 | 72 | |
| Full load continuous running time | 4.32 | 5.4 | 4.8 | 4.3 | 4 | 4 | 3.5 | 3.6 | 3.3 | 3 | 3.6 | 3.2 | 2.9 | |
| recharge mileage(km) | 6.5 | 8.1 | 7.2 | 5.1 | 4.8 | 4.8 | 4.2 | 4.3 | 4 | 3.6 | 4.3 | 3.8 | 3.2 | |
| ***Large wheel pressure(KN) | 14.4 | 25.8 | 42.6 | 64.5 | 77.7 | 94.5 | 110.4 | 142.8 | 174 | 221.4 | 278.4 | 343.8 | 265.2 | |
| reference weight(t) | 2.8 | 3.6 | 4.2 | 5.5 | 5.9 | 6.5 | 6.8 | 7.6 | 8 | 10.8 | 12.8 | 14.6 | 26.8 | |
| Recommended rail model | P15 | P18 | P18 | P24 | P24 | P38 | P38 | P43 | P43 | P50 | P50 | QU100 | QU100 | |
| Description: 1. Load capacity, table size, rail inner distance can be designed and manufactured according to customer needs; 2. Optional wireless remote control device (domestic or imported); 3. Optional automatic stop when encountering people, limit limit device; 4. Optional maintenance-free battery, lithium battery, explosion-proof battery, high temperature battery, etc.; 5. Optional DC brush motor, DC brushless motor; 6. Optional domestic electrical appliances, imported electrical appliances. |
||||||||||||||
|
