|Material:||20CrMnMo,34CrNi3Mo,34CrNiMo6, 38CrMoAl,40CrNiMo,18Cr||Attributes:||Engineering Car Forgings, Engineering Car Parts|
|Heat Treatment::||Hardening, Quench+ Temper||Quality Control::||PFMEA, PPAP, APQP, Control Plan, MSA|
|Machining Process::||CNC Lathe, CNC Milling Center||Specification::||L<18000mm,D<1500mm,|
ODM Metal Forging Parts,
Kingrail Metal Forging Parts,
CNC Machined Parts 34CrNiMo6
34CrNiMo6 Material Metal Forging Parts , CNC Machined Parts Kingrail ODM
Production of 34CrNiMo6 Material Metal Forging Parts , CNC Machined Parts Kingrail ODM
Kingrail can offer you investment casting parts, railway casting parts, railway parts, excavator machinery parts, mining machinery parts, engineering machinery, agricultural machinery parts, sand casting, bucket tooth, auto parts, stamping & forging, and valve parts. We are capability in manufacture non-standard metal machining.
Customized Forging and CNC Machined Parts-Metal Forging Parts
Forging quality inspection items are as follows:
(1) Geometry and size
Generally, the external dimensions of forgings are detected with measuring tools such as steel rulers, calipers, and templates; die forgings with complex shapes can be accurately detected by scribing.
(2) Surface quality
If there are cracks, crushing and folding defects on the surface of the forgings, they can generally be found with the naked eye. Sometimes the cracks are very small, and when the depth of the fold is unknown, it can be observed after cleaning the shovel; if necessary, the flaw detection method can be used for inspection.
(3) Internal organization
Whether there are cracks, inclusions, looseness and other defects inside the forging, the macroscopic structure on the forging section can be checked with the naked eye or with a magnifying glass of 10 to 30 times. The commonly used method in production is acid etching inspection, that is, the sample is cut from the part of the forging that needs to be inspected, and the defects of the macrostructure on the section can be clearly displayed by etching with acid solution, such as the distribution of forging streamlines, cracks and inclusions. Wait.
(4) Metallographic inspection
With the help of metallographic microscope to observe the inspection method of the fracture structure of forgings, the carbide distribution, grain size and decarburization depth can be checked.
(5) Mechanical properties
The mechanical properties test items are mainly hardness, tensile strength and impact toughness. Sometimes according to the design requirements of the parts, it can also be used for cold bending test and fatigue test.
The above quality inspection items are sometimes used separately according to the design requirements and actual production conditions, sometimes they are inspected piece by piece, and sometimes they are sampled for each batch of forgings. Through quality inspection, it is possible to assess whether the forgings are qualified . For defective forgings, the causes should be analyzed and measures to prevent defects should be proposed
Our workshop covers over 8000㎡, which include electric furnaces, die forgings machines, CNC machining center, heat treatment and all kinds of testing equipment. With these advanced facilities & instruments, we are able to supply the high quality castings and forgings to our customers, and make products meeting comprehensive inspection requirements on chemical composition, mechanical properties, non-destructive testing and high precise dimensional inspections.
Forgings involve many industries like mining, engineering, automobile, oil and gas. Material has carbon steel, alloy steel,stainless steel, brass and aluminium. Unit weight range from 0.05kg-1500kg.
Main Production Equipment List of Customized Forging and CNC Machined Parts-Metal Forging Parts
|1||Vertical lathe||VTC6070||36||working||Finishing workshop|
|4||Multi-function machine||HTC2050n||20||working||Finishing workshop|
|6||Steyr CNC lathe||CK7520ACK50||8 6||working||Finishing workshop|
|7||Milling and drilling machine||XZ8210C||2||working||Finishing workshop|
|8||CNC milling and drilling machine||TY-ZT5060||6||working||Finishing workshop|
|9||OD milling machine||MB32BX500||2||working||Finishing workshop|
|10||Air compressor||HLGD-75||1||working||Finishing workshop|
|11||Vertical drilling machine||Z5140A||6||working||Finishing workshop|
|12||CNC suspended tapping machine||SKXFGS.PS||5||working||Finishing workshop|
|13||CNC hobbing machine||YK3180CNC3||6||working||Finishing workshop|
|14||Marking machine||HZP-90*160D etc.||6||working||Finishing workshop|
|15||Natural gas furnace||WLS-DZ-001 etc.||2||working||Forging workshop|
|16||Air hammer||C41-2000 etc.||15||working||Forging workshop|
|17||Press||J53-2500C etc.||18||working||Forging workshop|
|18||Ring rolling machine||D51-450A etc.||8||working||Forging workshop|
|19||Electric furnace||KGPS-600KW etc.||10||working||Forging workshop|
|20||Compressor||175A-20.5 etc.||3||working||Forging workshop|
|21||CNC sawing machine||GZ4232||16||working||Raw material workshop|
|22||Automatic normalization furnace||HRDW-600KW||8||working||Heat treatment workshop|
|23||Suspended gas normalization furnace||WD-0138||2||working||Heat treatment workshop|
|24||Shot blasting machine||Q3210,Q69 etc.||4||working||Finishing workshop|
