Product Details:
Place of Origin: China
Brand Name: Kingrail
Certification: ISO
Model Number: precision casting
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: standard export package, or as per customer request
Delivery Time: 1-30 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000000ton

Steel Investment Casting Parts Die Casting For Motorcycle Engine ODM

Description
Material:: Stainless Steel, Carbon Steel, Alloy Steel Specification: Customized
Product Name:: Casting Stamping Parts Application: Industry Machinery, Automotive, Electricity
Process:: Investment Casting Surface Treatment: Zinc Plating, Painting, Powder Coating, Electro Polishing
Testing Facilities:: Spectrometer, CMM, Callipers, Micrometer, Projector Load
High Light:

Steel Investment Casting Parts

,

Motorcycle Investment Casting Parts

,

ODM Steel Casting Parts

Production of casting steel parts precision steel investing cast motorcycle engine parts of aluminium die casting

Castings are metal forming objects obtained by various casting methods, that is, the smelted liquid metal is injected into the pre-prepared casting mold by pouring, injection, suction or other casting methods, and after cooling, after grinding and other subsequent processing methods. , the resulting object of certain shape, size and properties.



casting steel parts precision steel investing cast motorcycle engine parts of aluminium die casting

The inspection of castings mainly includes dimensional inspection, visual inspection of appearance and surface, chemical composition analysis and mechanical performance test. For castings that are more important or prone to problems in the casting process, non-destructive testing is also required, which can be used for ductile iron castings Non-destructive testing techniques for quality testing include liquid penetrant testing, magnetic particle testing, eddy current testing, radiographic testing, ultrasonic testing, and vibration testing.



For internal defects, the commonly used nondestructive testing methods are radiographic testing and ultrasonic testing. Among them, the radiographic inspection effect is the best, it can obtain an intuitive image reflecting the type, shape, size and distribution of internal defects, but for large-thickness large castings, ultrasonic inspection is very effective, and the position of internal defects can be measured more accurately. , equivalent size and distribution.
1) Radiographic inspection (Micro focus XRAY)
X-rays or γ-rays are generally used as radiation sources for ray inspection, so equipment and other auxiliary facilities for generating ray are required. When the workpiece is placed in the ray field, the radiation intensity of the ray will be affected by the internal defects of the casting. The radiation intensity emitted through the casting varies locally with the size and nature of the defect, forming a radiographic image of the defect, which is imaged and recorded through a radiographic film, or detected and observed in real time through a fluorescent screen, or detected by a radiation counter. Among them, the method of imaging and recording by radiographic film is the most commonly used method, which is commonly referred to as radiographic inspection. The defect image reflected by radiography is intuitive, and the shape, size, number, plane position and distribution range of defects are all It can be shown, but the depth of the defect cannot be reflected in general, and special measures and calculations are needed to determine it. The international foundry industry network has applied the method of ray computed tomography, which cannot be popularized due to the expensive equipment and high use cost, but this new technology represents the future development direction of high-definition ray detection technology. In addition, the use of a microfocus X-ray system that approximates a point source actually eliminates the blurry edges created by larger focus devices, resulting in sharper image outlines. Using a digital imaging system can improve the signal-to-noise ratio of the image and further improve the clarity of the image.
2) Ultrasonic testing
Ultrasonic testing can also be used to inspect internal defects. It uses the propagation of sound beams with high-frequency sound energy inside the casting to generate reflections when they hit the internal surface or defects to find defects. The magnitude of the reflected acoustic energy is a function of the directivity and nature of the interior surface or defect and the acoustic impedance of such a reflector, so the acoustic energy reflected from various defects or interior surfaces can be applied to detect the presence of defects, wall thickness or surface the depth of the defect. As a widely used non-destructive testing method, ultrasonic testing has the main advantages of: high detection sensitivity, which can detect small cracks; large penetration ability, which can detect thick section castings. Its main limitations are: difficult to interpret reflection waveforms for discontinuous defects with complex contour dimensions and poor directivity; for undesired internal structures such as grain size, microstructure, porosity, inclusion content or fine dispersion Precipitates, etc., also hinder waveform interpretation; in addition, it is necessary to refer to standard test blocks during detection.

Main Testing and Inspection Device of casting steel parts precision steel investing cast motorcycle engine parts of aluminium die casting

No. Device Type Qty Status Note
1 End quenching machine DZJ-I 1 working Testing
2 Electric resistance furnace SX2-8-12 2 working Testing
3 Inverted metallurgic microscope 4XCE 1 working Inspection
4 High temperature box resistance furnace SX2-4-13 1 working Testing
5 Automatic digital display Rockwell hard-tester 200HRS-180 1 working Inspection
6 Electronic Brinell hardness tester THB-3000 1 working Inspection
7 HR-150B Rockwell hardness tester HR-150B 1 working Inspection
8 Rapid multi-element analyzer JS-DN328 1 working Inspection
9 Electric arc furnace JSDL-8 1 working Testing
10 Rapid multi-element analyzer(C & S) JS-DN328 1 working Inspection
11 Infrared thermometer AR872 2 working Inspection
12 Portable chemical composition analyzer AR872 2 working Inspection
13 Test specimen sampler KW30-6 1 working Inspection



Main Testing and Inspection Device

No. Device Type Qty Status Note
1 End quenching machine DZJ-I 1 working Testing
2 Electric resistance furnace SX2-8-12 2 working Testing
3 Inverted metallurgic microscope 4XCE 1 working Inspection
4 High temperature box resistance furnace SX2-4-13 1 working Testing
5 Automatic digital display Rockwell hard-tester 200HRS-180 1 working Inspection
6 Electronic Brinell hardness tester THB-3000 1 working Inspection
7 HR-150B Rockwell hardness tester HR-150B 1 working Inspection
8 Rapid multi-element analyzer JS-DN328 1 working Inspection
9 Electric arc furnace JSDL-8 1 working Testing
10 Rapid multi-element analyzer(C & S) JS-DN328 1 working Inspection
11 Infrared thermometer AR872 2 working Inspection
12 Portable chemical composition analyzer AR872 2 working Inspection
13 Test specimen sampler KW30-6 1 working Inspection
