DIN 536 A100 Crane Rail , Train Rail Steel 12m 10m Size 900A Material
| Place of Origin | China |
|---|---|
| Brand Name | kingrail |
| Certification | ISO |
| Model Number | crane rail |
| Minimum Order Quantity | Negotiable |
| Price | Negotiable |
| Packaging Details | standard export package, or as per customer request |
| Delivery Time | 1-30 working days |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 1000000000ton |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Standard | AiSi, ASTM, Bs, DIN, GB, JIS | Bolt Hole Diameter | 22mm 24mm, As Customer's Requirement |
|---|---|---|---|
| Grade | Q235/55Q/U71Mn/75V/50Mn/45Mn | Length | 6-12m |
| Rail Gauge | Normal Gauge | Specification | 4kg/m, 8kg/m 12kg/m, 15kg/m, 18kg/m, 22kg/m, 24kg/M,38-60 |
| Highlight | DIN A100 Crane Rail,A100 Crane Rail 10m,Train Rail Steel 12m |
||
Product Description
DIN 536 A100 Crane Rail , Train Rail Steel 12m 10m Size 900A Material
Introduction of DIN 536 A100 Crane Rail , Train Rail Steel 12m 10m Size 900A Material
Our crane rail is used in overhead gantry and floor-mounted cranes in ports, as well as warehouses and shipyards around the world!
CHEMICAL COMPOSITION (%) INDICATIVE FOR DIN 536 A100 Crane Rail , Train Rail Steel 12m 10m Size 900A Material
| CARBON : | 0.60 - 0.80 |
| SILICON : | < 0.50 |
| MANGANESE : | 0.80 - 1.30 |
| PHOSPHOROUS : | < 0.045 |
| SULPHUR : | < 0.04 |
MECHANICAL PROPERTIES OF DIN 536 A100 Crane Rail , Train Rail Steel 12m 10m Size 900A Material:
| STANDARD LENGTH : | 12.00 m |
| ELONGATION (%) : | 8 min. |
| CALCULATED MASS : | 74.3 kg/m |
| TENSILE STRENGTH (Min): N/mm2 : | 880 |
| YIELD POINT (Min): N/mm2 : | 440 |
Delivery and package of DIN 536 A100 Crane Rail , Train Rail Steel 12m 10m Size 900A Material
