Welded Type Forged Steel Flexible Self Locking Crane Rail Clamp Clips

Certification
China Maanshan Kingrail Technology Co.,Ltd. certification
I'm Online Chat Now

Welded Type Forged Steel Flexible Self Locking Crane Rail Clamp Clips

Welded Type Forged Steel Flexible Self Locking Crane Rail Clamp Clips
Welded Type Forged Steel Flexible Self Locking Crane Rail Clamp Clips
Welded Type Forged Steel Flexible Self Locking Crane Rail Clamp Clips Welded Type Forged Steel Flexible Self Locking Crane Rail Clamp Clips Welded Type Forged Steel Flexible Self Locking Crane Rail Clamp Clips Welded Type Forged Steel Flexible Self Locking Crane Rail Clamp Clips Welded Type Forged Steel Flexible Self Locking Crane Rail Clamp Clips Welded Type Forged Steel Flexible Self Locking Crane Rail Clamp Clips

Large Image :  Welded Type Forged Steel Flexible Self Locking Crane Rail Clamp Clips

Product Details:
Place of Origin: China
Brand Name: Kingrail
Certification: GB/T 1222,DIN 17221
Model Number: WT01
Payment & Shipping Terms:
Minimum Order Quantity: 10000
Price: USD$1-10 PER PC
Packaging Details: bulk bags and pallets or customized package
Delivery Time: 1-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100000000PCS PER YEAR

Welded Type Forged Steel Flexible Self Locking Crane Rail Clamp Clips

Description
Material: Q235 Or Q345 Steel Forging Forming Size: 15mm
Color: Zinc Plated Or Plain Usage: Fastened To The Crane Beam
High Light:

Self Locking Crane Rail Clamp Clips

,

Welded Type Crane Rail Clamp Clips

,

Forged Steel Rail Clamp Clips

Welded Type Forged Steel Flexible Self-Locking Crane Rail Clamp Clips

These are forged steel high quality crane rail clip.  five-year quality assurance around the world except for non-human damage and force majeure provided by Kingrail. Or free replacement for any quality problem.  Our goal is to supply the better products to all over the world and looking forward to have your long-term partner relaitionship in China.





Product Introduction of the Crane Rail Clips

crane rail clip is a new design scheme,which is demanding for the minimum width of steel plate is much small.

In the crane rail system, can largly save the raw materials. It is also the self-locking, vulcanizing rubber tongue rail fixed part.

Rail clip materials are usally Q235 or Q345 steel forging forming or the the steel plate material with same level is to keep better fastness.



Product Specification of the 8119/15/40 Crane Rail Clips

Product Type Application Rubber Tongue Size

Weight

(Piece)

Horizontal Distance
Crane Rail Clips 8119/15/40 With rubber pad Depth 14mm 1.74kg 15mm
Crane Rail Clips 8119/15/40 Without rubber pad Depth 21mm 1.84kg

15mm



Welded Type Forged Steel Flexible Self Locking Crane Rail Clamp Clips 0

Feature and Application of the Crane Rail Clips

Our flexible rail clip is automatically self- locked through the wedge-shaped structure and the two slabs of each other.

The control of rail and crane beam tolerances is good enough,which gurantee the prestressing of the base and the lasting contact between the track and the base of rail clip . Effectively and greatly reduce noise and improve working environment.

It can be used in lifting tonnage  800 tons wharf, steel mills, shipyards, automated production base and other rail system.

Welded Type Forged Steel Flexible Self Locking Crane Rail Clamp Clips 1

Packaging Details: Wooden cases packing or customized package requests.

Delivery Detail: According to your requirements, accept L/C or T/T payment.



We are in the city of Maanshan , where is the Baowu Group MASTEEL Rail Transit Materials Technology Co. Ltd the 9th biggest steel producer globally.Here is the oringinal source of steel material with internatinal standards such as BS,AAR, JIS ,IRS and Gost, which ensure customer to get exceptianal quality safety critical railway components at a very cometitive price.



So please send your inquiry with drawing or specifcation details, will revert you good offer,thanks!
