Product Details:
|
| Available Material: | High Strength Steel, Stainless Steel, Carbon Steel | International Standard: | DIN, ANSI, GB, JIS, Bsw, GOST |
|---|---|---|---|
| Used: | Railway Fastening Syestem | Head Type: | Squre And Round Bolt |
| Class/Grade: | 12.9 | Surface Finishing: | Hot DIP Galvanizing, Black |
| Finish: | Black ,plain Or Customzed Painting Etc | Specification: | M24 |
| Name: | Nut And Bolt Grade 12.9 Top Quality Square Head And Nuts Lag Heavy Head Railway Fish Plate Bolt Fishtail Screw | ||
| High Light: | M24 Railroad Track Bolts,Railroad Track Fishtail Bolt,M24 Railway Sleeper Spike |
||
Fish Tail Bolt M24 Railroad Track Bolts And Nuts Track Part Railway Sleeper Spike
Product Introduction
1.The screw spike material is Q235-A steel with standard GB700.
2.The upper thread screw spike is M24 with the provisions of GB196, while thread tolerances as specified in the GB197 8g.
3.The lower part of the thread spiral spike for M25.6 x 6 - d24.0/25.6 threads, teeth as high as 3.25 - 00.25mm.
4. we make the end of the spiral spike according to the provisions of GB2. 4.5.1 cone surface of the spiral spike burst fracture is not allowed to extend to the forging shaft.
5.2The upper thread screw spike is not allowed with bumps and burr free running thread gauge, influence the use of double cusp, scratches and do not allow incomplete thread
5.3The lower thread tooth shaped screw spike should be neat, threaded integrity, which do not allow splitting traces.
5.4The spiral spike surface will not to affect the use of the dent, burr, flash, burn and oxide skin.
6.Sreal spiral spike tension test, when the load is 130kN.
| Name | steel zinc plating screw spikes |
| Grade | 4.8 6.8. 8.8 10.9 |
| Standard | DIN,ISO,JIS, ANSI,BS |
| Material | carbon Steel, alloy Steel |
| Size | customized |
| Surface treatment | black,galvanized, dacromet, alloy permeability,etc. |
Fish Tail Bolt m6 m25 Railroad Track Bolts and Nuts Track Part Railway Sleeper Spike
Fish bolt shapes Classification and Diffenrent Used Situation:
Generally, the countersunk head is used in places where the surface is required to be smooth without protrusions, because the countersunk head can be screwed into the part. Round heads can also be screwed into parts. The tightening force of the square head can be larger, but the size is large. In addition, in order to meet the needs of locking after installation, there are holes in the head and holes in the rod. These holes can prevent the bolts from loosening when they are vibrated. Some bolts without threads should be made thin, called thin-waisted bolts. This kind of bolt is beneficial to the connection under variable force. There are special high-strength bolts on the steel structure, the head will be larger, and the size will also change. In addition, there are special uses: for T-slot bolts, which are most used on machine tool fixtures, with special shapes, and both sides of the head should be cut off. Anchor bolts, used for machine and ground connection and fixing, come in many shapes. U-bolts, as previously described. etc. There are also special studs for welding. One end has a thread and the other end is not. It can be welded to the part, and the other side can directly screw the nut. The English name of the riding bolt is U-bolt. It is a non-standard part. The shape is U-shaped, so it is also called a U-bolt. There are threads on both ends that can be combined with nuts. It is mainly used to fix tubular objects such as water pipes or sheets such as automobile plates. Springs are called riding bolts because of the way they fix things like a person rides a horse.
Fishtail bolt inspection:
Bolt inspection is divided into manual and machine. Manual is the most primitive and the most commonly used consistent detection method. In order to minimize the outflow of defective products, general production enterprise personnel inspect the packaged or shipped products by visual means to exclude defective products (defective products include tooth damage, mixed materials, rust, etc.).
Another way is automatic machine detection, mainly magnetic particle inspection. Magnetic particle inspection is to use the interaction between the leakage magnetic field at the defect of the bolt and the magnetic powder, aiming at the difference between the magnetic permeability of the bolts (such as cracks, slag inclusions, mixed materials, etc.) and the magnetic permeability of steel, these materials are discontinuous after magnetization.
Production Details:
Railway parts products we can provide:
1, Rail Spike Series: Rail Screw Spike, rail Dog Spike, rail Elastic Spike etc.
2, Track Bolt series: Track Bolt, Segment Bolt, Metro Bolt, Tunnel Bolt, Hex Bolt, Square Bolt, Turnout Bolt, Fishtail Bolt, T bolt etc
3, Rail Clip series: Nabla rail Clip, Elastic rail Clip, SKL rail Tension Clamp, O rail Clip, Gauge Lock Clip etc
4, Steel Rails series: Railway rails, Crane Rails, Mining Rails, Over the head Rails, etc
5, Steel rail wheels series: Train Wheels, Crane Wheels, Hi-rail vehicle wheels, etc
6, Other materials and accessories: Rail Gauge Insulator, rail rubber Pad, rail Fish plate, Nut, rail Plastic Dowel, rail Tie plate, Spring Washer, Flat Washer, Cast Iron Insert, Anti Creeper, rail Gauge Rod etc.
We also make rail fastenings for crane rail and elevator guide rail, along with other related products. We manufacture according to GB/TB (Chinese national standards and railway standards), AREA, UIC, BS, DIN, ASTM, and AS standards.
Our products are mainly made through hot forging.
The threads of rail screw spikes are made by hot rolling with special threading machines.
We produce metric threads, BS, BSW, TR thread, or round threads.
Our high strength bolts come in different specifications of Class 4.8, 4.6, 5.6, 5.8, 6.8, 8.8, 10.9, and 12.9. A variety of non-standard fastening is also available. We can customize our products using customer drawings or samples as well.
Why choose us:
1. The company is in a leading position in the industry and has obtained SGS-ISO9001: 2008 quality system certification and CRCC certification. Quality is guaranteed.
2. We have 8 professional sales staff and more than 60 professional engineers. Can provide professional and fast suggestions and quotations for your railway customized products
3. Ma′anshan is a port city. We can provide you with faster shipping services
4.20 years of production and sales experience. Deal with all kinds of after-sales problems for you in time.
