Product Details:
|
| Standard:: | IN | Bolt Hole Diameter:: | 22mm 24mm, As Customer's Requirement |
|---|---|---|---|
| Grade:: | 55Q/U71Mn,U71Mn | Length: | 9-12M |
| Rail Gauge:: | Normal Gauge | Specification:: | ISCR50,60,70,80,100,120 |
| High Light: | Q235 Steel The Third Ramp Rail,Q235 Steel Rail Track,110mm Height Rail Track |
||
The third ramp rail Aford 26 Q235 steel 110 height rail track
Automotive rail ramps are made for where all cars come to be loaded onto trains for rail transport or are unloaded at the end of their rail journeys. Most of the ramps are located in metro areas, near auto manufacturing plants and their major distribution centers.
Tee Rail & Light Rail
Tee rail sections are used in a wide variety of applications ranging from transit authority systems to Heavy haul railways.
Light rail sections (85 lb/yd and less) are used for mining, industrial, and crane applications.
IN Standard Rail for Railway
| ISCR STEEL RAIL INDIA STANDRAD | |||||||
| SIZE | DIMENSION(mm) | WEIGHT (kg/m) | MATERIAL | LENGTH (m) | |||
| HEAD A (mm) | HEIGHT B (mm) | BASE C (mm) | WEB D (mm) | ||||
| ISCR50 | 51.2 | 90 | 90 | 20 | 29.8 | 55Q/U71Mn | 9-12 |
| ISCR60 | 61.3 | 105 | 105 | 24 | 40 | 55Q/U71Mn | 9-12 |
| ISCR70 | 70 | 120 | 120 | 28 | 52.8 | U71Mn | 9-12 |
| ISCR80 | 81.7 | 130 | 130 | 32 | 64.2 | U71Mn | 9-12 |
| ISCR100 | 101.9 | 150 | 150 | 38 | 89 | U71Mn | 9-12 |
| ISCR120 | 122 | 170 | 170 | 44 | 118 | U71Mn | 9-12 |
Kingrail, as a specialized rail fastener manufacturer, provides a complete line of products, including rail fastening, anchor, rail joint, rail clip, rail screw, anchor bolt, rail clamp plate, rail fishplate, and fishplate bolt for connecting rail tracks.
We also make rail fastenings for crane rail and elevator guide rail, along with other related products. We manufacture according to GB/TB (Chinese national standards and railway standards), AREA, UIC, BS, DIN, ASTM, and AS standards.
Our products are mainly made through hot forging.
The threads of rail screw spikes are made by hot rolling with special threading machines.
We produce metric threads, BS, BSW, TR thread, or round threads.
We believe in quality first principle of our company .What we sell not only the parts but also our industry knowledge ,experiences and service.
So please send your inquiry with drawing or specifcation details, will revert you good offer!
