Product Details:
Place of Origin: China
Certification: ISO
Payment & Shipping Terms:
Minimum Order Quantity: 1
Delivery Time: 60
Payment Terms: L/C, T/T, Western Union

AAR Railway Wheelset for Wagon Locomotive on Hot Sale

Description
Type:: Wheelset Place Of Origin:: China
Material:: Iron, Steel, Gray Iron,Nodular Cast Iron, Iron, Steel Quality:: High Quality
Packaging: Cartons ,wooden Cases Or According To Customers' Requirements

Overview

Quick Details
Type:
wheelset....
Material:
CL65
Dimensions (L x W x H) (mm):
600mm-1250mm
Place of Origin:
Anhui, China
Model Number:
762mm
Origin:
Maanshan
Warranty:
5years
Materia:
Carbon steel
Package:
Steel package
Service:
engineers avaiable
Dimensions:
according to your drawing
Supply Ability
Supply Ability
10000 Pair/Pairs per Year railway wheel sets , train parts , rail wheel
Packaging & Delivery
Packaging Details
wooden package .standard export package
Maanshan forging carbon steel wheel axles Maanshan forging alloy steel wheel axles
Port
SHANGHAI
Lead Time:
45DAYS






AAR standard Wheelset for Railway Vehicles

760mm wheelset

1. Drawing

760mm wheel +2160mm axle

AAR standard Wheelset for Railway Vehicles

AAR standard Wheelset for Railway Vehicles

2.Main dimension:

Product NO. MTJ760WHEELSET
Wheel outer diameter 760 mm
Wheel material CL60
Axle length 2160 mm
Axle material LZ50
Distance between the internal wheel faces 1353 mm





3.We can offer:

Railway wheel
Thread diameter, d/mm width of rim, l1/mm gauge/mm weight /kg axle loade/t
650-2000 95-160 narrow gauge, 1000, 1435 165-1050 12-35







Railway axle
Length, L/mm Distance between two journal centers,L1/mm Axle journal diameter,D1/mm wheel seat diameter,D2/mm axle body diameter,D3/mm alxe load/t
2062-2356 1905-2007 100-180 155-241 138-215 12-35
Forging Part



Forged steel rail wheel and wheelset



Material ER6,ER7,ER8,ER9,R7T,R8T,R9T,CL60
Dimension According to your drawings
Application Heavy industrial equipment
Inspection Chemical composition; UT,MT; mechanical property; dimension check
Standard IRS,BS,UIC,AAR,BN,GB,TB/T,EN
QC Doc Chemical composition report mechanical properties report; UT test report; heat treatment report; dimensions check report.
Forging Processing Ingot---forging---heat-treatment---rough machining---UT.MT---Q+T---inspection---finishing machining---UT.MT---packing
Heat Treatment Normalized / Annealed / Quenched / tempered

AAR standard Wheelset for Railway Vehicles



Maanshan forging steel wheel axles

Packaging & Shipping



Maanshan forging stainless steel wheel axles
