3V Railway Sleeper Screw Spike According To NF F500-06 For Rail Fastening

Name: 3V Railway Sleeper Screw Spike According To NF F500-06 For Rail Fastening
Brand: Maanshan Kingrail Technology Co.,Ltd.
SKU: Screw Spikes
Availability: InStock

Brand Name:	Kingrail
Model Number:	Screw Spikes
MOQ:	Negotiable
Price:	Negotiable
Delivery Time:	1-30 working days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO

Material::

Aluminium, Plastic, NICKEL, Nylon, Stainless Steel For Screw Spike

Standard::

GB, DIN, ISO, ANSI, ASME, IFI, JIS

Application::

Building, Furniture, Sanitary, Electronics, Traffic For Screw Spike

Surface Treatment:

Phosphated(black,grey), Galvanized(bule,white,color), Ruspert, Dacromet Etc

Type Head:

Pan, Flat, Truss, Hex Washer ,Wafer...

Sizes Dia:

#4-#16 (2.5mm-8mm)

Name:

Rail Fastening/ Track Spike/ Dog Spike Railroad Rail Sleeper Screw Spike With Round Thread

Packaging Details:

standard export package, or as per customer request

Supply Ability:

1000000ton

Highlight:

3V Railway Sleeper Screw Spike

Rail Fastening Railway Sleeper Screw Spike

Product Description

Rail sleeper screws are used to fix base plates and ribbed base plates to wooden sleepers. Kingrail Parts can provide a range of rail sleeper screw spikes that meet international standards such as BS, ASTM and DIN.

Our rail sleeper screws 3V meet NF F50-006 standards. Grade 4.6 and 5.6, mechanical properties meet the requirements of NF F 500006, tensile strength 700Mpa(min), elongation 12%(min), cold bending 30 degrees without cracks.

Specifications:

Grade: 4.6, 5.6

Material: Q235, 35#

Surface treatment: normal (oiled), black spray paint, galvanized, hot dip galvanized

Type	Dimension(mm)	Weight(Kg)
V20-135	M20×135	0.438
V23-115	M23×115	0.48
V23-135	M23×135	0.55
V23-155	M23×155	0.62
V23-215	M23×215	0.78
V26-115	M26×115	0.55

Contact us

Please contact us for more information and quotation.
