60t Goods Railway Freight Wagon with Welded Bogie for Sale from China
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Track Gauge | 1435mm,1067mm,1000mm、762mm、600mm,1524mm、1520mm | Load | 50 Ton,60 Ton,70 Ton |
|---|---|---|---|
| Speed | Less Than 120 Km/h | Bogie Type | Welded Bogie |
| Highlight | Welded Bogie Railway Freight Wagon,60 Ton Railway Freight Wagon,60 Ton Goods Railway Freight Wagon |
||
Product Description
The N17 flat wagon we produce is a special vehicle for general railway cargo transportation, suitable for 1435mm standard gauge railway.
It can not only be used to transport general cargo such as wood, steel, sleepers, cars, tractors, boxed goods, large concrete prefabricated beams, machinery and equipment, but also can be used for railway container transportation, equipped with movable side panels, and even for transporting sand, gravel, ore, etc.
We can also design and manufacture other flatbed wagons according to the specific requirements of customers.
Specifications:
| Application | Freight transport wagon by railway |
| Load | 60t |
| Tare weight | 21t |
| Gauge | 1435mm |
| Wheel diameter | 840mm |
| Number of axles | 4 |
| Fixed axle distance of bogie | 1750mm |
| Bogie type | K2 Casting bogie |
| Coupler type | #13 coupler |
| Coupler center height | 880mm |
| Length | 13938mm |
| Active side plate height | 420mm |
| Min radius | 145m |
| Brake type | Air brake +park hand brake |
| Brake ratio | 9.8 |
| Design speed | 120km/h |
| Limit gauge | Comply with Comply GB146 1-83 ‘standard gauge railway rolling stock gauge’ |
Get more information
Please contact us for free quotation and assistance.
